Televes EK1672plus coaxial underground cable black, 1.6/7, 100m ring

In stock

SKU: 22922

Price on request

€2.52

€0

Overview

The EK1672plus has a glued foil and the shielding level is > 100dB. It is also weather and age resistant and free of halogens, with meter printing and low attenuation.

Property	Value
Sheath color:	black
Outer diameter approx.:	10.1 mm
Dielectric:	Polyethylene, foamed (Foam PE)
Outer conductor form:	Foil + braid
Characteristic impedance:	75 Ohm
Inner conductor diameter:	1.6 mm
UV-resistant:	yes
Sheath material:	Polyolefins
Outer conductor diameter:	7.2 mm
Inner conductor material:	copper
Inner conductor class:	Class 1 = single wire
Outer conductor material:	aluminum
Reinforcement:	no
Permissible external cable temperature during assembly/handling:	-5 to 60 °C
Permissible Cable external temperature after installation without vibration:	-15 to 65 °C
Halogen-free according to EN 60754-1/2:	no
Inner conductor surface:	bare
Outer conductor surface:	tinned
Number of shielding layers:	3
Specification of sheath material:	Polyethylene (PE)
Fire behavior class according to EN 13501-6:	Fca
Laying in the ground:	yes
