ColorWhite
HANESR2339010
GTIN4012002246016
LockableNo
Connection typePlug-in terminal
Antibacterial treatmentNo
Number of Units2
Number of modules (for modular construction)4
Number of phases1
Number of active contacts (approx.)2
Surface finishFrosted
Ejection mechanismNo
Mounting typeSnap-on fastening
Residual current protectionNo
Frequency50 to 60 Hz
Suitable for protection class (IP)IP20
Device width45 mm
Device height90 mm
Device depth40 mm
Halogen freeYes
Insulated installationNo
Min. depth of the device box45 mm
With loop-through functionYes
With on/off switchNo
With micro fuseNo
With functional lightingNo
With hinged lidNo
With orientation lightingNo
With signal lampNo
With built-in USB power supplyNo
With increased contact protectionYes
Mounting typeOther
Nominal voltage250V
Rated current16A
SurfaceUntreated
RAL number (similar)9010
Protective contactYes
Protective conductor contact roundNo
Special power supplyWithout special power supply
Text field/label areaNo
TransparentNo
Twisted central insertYes
MaterialOther
Material qualityThermoplastic
Overvoltage protectionNo
