Insert Module TypeLight switch covers
ColorWhite
HAN069641
GTIN3245060696412
LockableNo
Connection typePlug-in terminal
Antibacterial treatmentNo
Number of Units1
Number of phases1
Number of active contacts (approx.)1
Printing/markingIP protection)
Surface finishFrosted
Ejection mechanismNo
Mounting typeFastening with screw
Residual current protectionNo
Frequency50 to 60 Hz
Suitable for protection class (IP)IP55
Device width64 mm
Device height64 mm
Device depth48 mm
Halogen freeYes
Insulated installationNo
With loop-through functionYes
With on/off switchNo
With micro fuseNo
With functional lightingNo
With hinged lidYes
With orientation lightingNo
With signal lampNo
With built-in USB power supplyNo
With increased contact protectionYes
Mounting typeFlush-mounted
Nominal voltage250V
Rated current16A
SurfaceUntreated
RAL number (similar)9100
Impact resistanceIK07
Protective contactYes
Protective conductor contact roundNo
Special power supplyWithout special power supply
Text field/label areaNo
TransparentNo
Twisted central insertNo
MaterialPlastic
Material qualityThermoplastic
Overvoltage protectionNo
