Insert Module TypeLight switch covers
ColorWhite
HAN077210
GTIN3245060772109
LockableNo
Connection typeScrew terminal
Antibacterial treatmentNo
Number of Units1
Number of modules (for modular construction)2
Number of phases1
Number of active contacts (approx.)1
Surface finishGlittering
Ejection mechanismNo
Mounting typeSnap-on fastening
Residual current protectionNo
Frequency50 to 60 Hz
Suitable for protection class (IP)IP20
Device width45 mm
Device height45 mm
Device depth38 mm
Halogen freeYes
Insulated installationNo
With loop-through functionYes
With on/off switchNo
With micro fuseNo
With functional lightingNo
With hinged lidNo
With orientation lightingNo
With signal lampNo
With built-in USB power supplyNo
With increased contact protectionNo
Mounting typeModule carrier
Nominal voltage250V
Rated current16A
SurfaceUntreated
RAL number (similar)9003
Impact resistanceIK04
Protective contactYes
Protective conductor contact roundNo
Special power supplyWithout special power supply
Text field/label areaNo
TransparentNo
Twisted central insertNo
MaterialPlastic
Material qualityThermoplastic
Overvoltage protectionNo
