Insert Module TypeLight switch covers
ColorWhite
HAN077503
GTIN3245060775032
LockableNo
Connection typeScrew terminal
Antibacterial treatmentNo
Number of Units1
Number of modules (for modular construction)1
Number of phases1
Number of active contacts (approx.)1
Surface finishGlittering
Ejection mechanismNo
Mounting typeSnap-on fastening
Residual current protectionNo
Frequency50 to 60 Hz
Suitable for protection class (IP)IP41
Device width22.5 mm
Device height45 mm
Device depth32 mm
Halogen freeYes
Insulated installationNo
With loop-through functionYes
With on/off switchNo
With micro fuseNo
With functional lightingNo
With hinged lidNo
With orientation lightingNo
With signal lampNo
With built-in USB power supplyNo
With increased contact protectionNo
Mounting typeFlush-mounted
Nominal voltage127V
Rated current15A
SurfaceUntreated
RAL number (similar)9003
Impact resistanceIK04
Protective contactNo
Protective conductor contact roundNo
Special power supplyWithout special power supply
Text field/label areaNo
TransparentNo
Twisted central insertNo
MaterialPlastic
Material qualityThermoplastic
Overvoltage protectionNo
