Insert Module TypeLight switch covers
ColorWhite
HAN572113
GTIN3245065721133
LockableNo
Connection typeScrew terminal
Antibacterial treatmentNo
Number of Units1
Number of modules (for modular construction)2
Number of phases1
Number of active contacts (approx.)1
Printing/markingOther
Surface finishGlittering
Ejection mechanismNo
Mounting typeSnap-on fastening
Residual current protectionNo
Frequency50 to 60 Hz
Suitable for protection class (IP)IP40
Device width45 mm
Device height45 mm
Device depth29.7 mm
Halogen freeYes
Insulated installationNo
With loop-through functionYes
With on/off switchNo
With micro fuseNo
With functional lightingNo
With hinged lidNo
With signal lampNo
With built-in USB power supplyNo
With increased contact protectionYes
Mounting typeModule carrier
Nominal voltage250V
Rated current10A
SurfaceUntreated
RAL number (similar)9003
Impact resistanceIK04
Protective contactYes
Protective conductor contact roundYes
Special power supplyWithout special power supply
Text field/label areaNo
TransparentNo
Twisted central insertNo
MaterialPlastic
Material qualityThermoplastic
Overvoltage protectionNo
