ELSO 275404 socket 2-way semi-recessed 16A JOY pure white

ELSO 275404 socket 2-way semi-recessed 16A JOY pure white

In stock

SKU: 433486

Price on request

€8.11

€0

Overview

2-way socket, color: pure white, semi-recessed, cover 83x103x26 mm made of thermoplastic for 55 installation boxes, protective contact sockets 16 A 250 V AC for flush mounting, protection class IP 20, screw terminals clamping range for copper conductors 1.5 mm and 2.5 mm, for the secure connection of aluminum conductors 2.5 mm without pre-treatment

Property	Value
Version:	SCHUKO
RAL number (similar):	9010
Number of units:	2
Color:	white
Suitable for protection class (IP):	IP20
Nominal voltage:	250 V
Nominal current:	16 A
Lockable:	no
With increased contact protection:	no
With hinged lid:	no
Mounting type:	other
Text field/labeling area:	no
Frequency:	50 Hz
Ejection mechanism:	no
Halogen-free:	yes
Overvoltage protection:	no
Residual current protection:	no
Special power supply:	without special power supply
Twisted central insert:	no
Print/marking:	without print
Connection type:	screw terminal
With fine fuse:	no
Fastening type:	claw/screw fastening
Material:	plastic
Material quality:	thermoplastic
Surface:	untreated
Surface finish:	glossy
For 'difficult conditions' (according to VDE):	no
Device width:	83 mm
Device height:	103 mm
Device depth:	26 mm
Insulated installation:	no
With loop-through function:	yes
With on/off switch:	no
With built-in USB power supply:	no
With function lighting:	no
With orientation lighting:	no
Impact resistance:	IK02
Transparent:	no
Protective contact:	yes
Round protective conductor contact:	no
Number of active contacts (round):	1
With signal lamp:	no
Number of phases:	1
Antibacterial treatment:	no

Characteristics

Manufacturer

HAN275404

GTIN4013984191950

LockableNo

Connection typeScrew terminal

Antibacterial treatmentNo

Number of Units2

Number of phases1

Printing/markingWithout imprint

Version

Surface finishGlittering

Ejection mechanismNo

Mounting typeClaw/screw fastening

Color

Residual current protectionNo

Frequency50Hz

Device width83 mm

Device height103 mm

Device depth26 mm

Halogen freeYes

Insulated installationNo

With loop-through functionYes

With on/off switchNo

With micro fuseNo

With functional lightingNo

With hinged lidNo

With orientation lightingNo

With signal lampNo

With built-in USB power supplyNo

With increased contact protectionNo

Mounting typeOther

Nominal voltage250V

Rated current16A

SurfaceUntreated

Impact resistanceIK02

Protective contactYes

Protective conductor contact roundNo

Special power supplyWithout special power supply

Text field/label areaNo

TransparentNo

Twisted central insertNo

MaterialPlastic

Material qualityThermoplastic

Overvoltage protectionNo
