Eaton Z-S109/W impulse switch, 110DC, 1W, 16A, 1TE, 265292

In stock

SKU: 219192

Price on request

€32.17

€0

Overview

Impulse switch, control voltage 110V DC, function: 1 changeover contact, rated current at 250V AC according to IEC/EN 60669-2-2: 16A, cap installation dimension 45mm, installation width 1TE (17.5mm), DIN rail mounting, terminal cross-section 0.5-10 qmm single and multi-wire / 0.5-6 qmm fine-wire with wire end ferrule

Property	Value
Width in modular spacing:	1
Rated switching current:	16 A
Control voltage 1:	110 V
Control voltage type 1:	DC
Control voltage type 2:	DC
Installation depth:	60 mm
Function:	mechanical switch
Mounting type:	DIN rail
Type of supply voltage:	DC
Supply voltage:	24 to 230 V
Max. incandescent lamp load:	2024 W
Max. fluorescent lamp load:	2500 VA
Max. fluorescent lamp load (duo circuit):	2500 VA
Max. fluorescent lamp load (parallel compensated):	2500 VA
Max. switching current (cos phi = 0.6):	24 A
Number of contacts as changeover contact:	1
