Eaton Z-S109/WW impulse switch, 110DC, 2W, 16A, 2TE, 265314

In stock
SKU: 219193
€88.53
Into a basketIn the basketGo

Overview

Impulse switch, control voltage 110V DC, function: 2 changeover contacts, rated current at 250V AC according to IEC/EN 60669-2-2: 16A, cap installation dimension 45mm, installation width 2TE (35mm), DIN rail mounting, terminal cross-section 0.5-10 mm² single and multi-wire / 0.5-6 mm² fine-wire with wire end ferrule

PropertyValue
Width in modular spacing:2
Rated switching current:16 A
Control voltage 1:110 V
Control voltage type 1:DC
Control voltage type 2:DC
Installation depth:60 mm
Function:mechanical switch
Mounting type:DIN rail
Type of supply voltage:DC
Supply voltage:24 to 230 V
Max. incandescent lamp load:2024 W
Max. fluorescent lamp load:2500 VA
Max. fluorescent lamp load (duo circuit):2500 VA
Max. fluorescent lamp load (parallel compensated):2500 VA
Max. switching current (cos phi = 0.6):24 A
Number of contacts as changeover contact:2

Characteristics

Type of voltage of the supply voltageDC
Supply voltage24 to 230 V
Max. fluorescent lamp load2500 VA
HABZ-S109/WW
ManufacturerEaton
HAN265314
GTIN4015082653149
Number of contacts as changeover2
Width in pitch units2
Installation depth60 mm
FunctionMechanical switch
Mounting typeDIN rail
Supply voltage24 to 230 V
