Eaton Z-S110/WW impulse switch, 110AC, 2W, 16A, 50Hz, 2TE, 265313

In stock

SKU: 219199

Price on request

€88.53

€0

Overview

Impulse switch, control voltage 110V 50Hz, function: 2 changeover contacts, rated current at 250V AC according to IEC/EN 60669-2-2: 16A, cap installation dimension 45mm, installation width 2TE (35mm), DIN rail mounting, terminal cross-section 0.5-10 qmm single and multi-wire / 0.5-6 qmm fine-wire with wire end ferrule

Property	Value
Width in modular spacing:	2
Rated switching current:	16 A
Control voltage 1:	110 V
Control voltage type 1:	AC
Control voltage type 2:	AC
Installation depth:	60 mm
Function:	mechanical switch
Mounting type:	DIN rail
Frequency of control voltage 1:	50 Hz
Type of supply voltage:	AC
Supply voltage:	24 to 240 V
Max. incandescent lamp load:	2024 W
Max. fluorescent lamp load:	2500 VA
Max. fluorescent lamp load (duo circuit):	2500 VA
Max. fluorescent lamp load (parallel compensated):	2500 VA
Max. Switching current (cos phi = 0.6):	24 A
Number of contacts as changeover contact:	2
