Eaton Z-SC240/1S1W surge protector ZS, 240V AC, 1S+1W, 265323

In stock

SKU: 219255

Price on request

€88.53

€0

Overview

Impulse switch with central control, control voltage 240V AC, function: 1 make contact and 1 changeover contact, rated current at 250V AC according to IEC/EN 60669-2-2: 16A, cap installation dimension 45mm, installation width 2TE (35mm), top hat rail mounting, terminal cross-section 0.5-10 mm² single and multi-wire / 0.5-6 mm² fine-wire with wire end ferrule

Property	Value
Width in modular spacing:	2
Rated switching current:	16 A
Control voltage 1:	240 V
Control voltage type 1:	AC
Control voltage type 2:	AC
Installation depth:	60 mm
Function:	mechanical for central control
Mounting type:	DIN rail
Frequency of control voltage 1:	50 to 60 Hz
Type of supply voltage:	AC
Supply voltage:	240 V
Max. incandescent lamp load:	1980 W
Max. fluorescent lamp load:	1020 VA
Max. fluorescent lamp load (duo circuit):	1820 VA
Max. fluorescent lamp load (parallel compensated):	1150 VA
Max. Switching current (cos phi = 0.6):	10 A
Number of contacts as normally open:	1
Number of contacts as changeover:	1
