HABDDC-100/2/I5/PR
HAN184918
GTIN4015081798179
Connection type main circuitScrew connection
Number of switches1
Designed as main switchYes
Designed as an EMERGENCY STOP deviceYes
Designed as a safety switchNo
Designed as a maintenance/repair switchYes
Version as reversing switchNo
Design of the actuating elementDoor coupling rotary drive
Rated operating voltage1000V
Rated continuous current Iu100A
Rated short-time withstand current Icw3kA
Color of the actuatorRed
Suitable for floor mountingYes
Suitable for front mounting 4-holeNo
Suitable for front mounting CentralNo
Suitable for distribution board installationNo
Suitable for intermediate constructionNo
Device typeComplete device in housing
Max. rated operating voltage Ue at AC1000V
Motor drive integratedNo
Motor drive optionalNo
Number of poles2
Protection class (IP), frontIP65
Protection class (NEMA)12
Voltage release optionalNo
LockableYes
