Eaton IS-100/2 main switch, 2p, 400V, 100A , 276283

In stock
SKU: 217990
€77.99
Into a basketIn the basketGo

Overview

Load switch with disconnecting function, design according to IEC/EN 60947-3, high wear resistance of the contacts, snap-on switching, toggle colour black, terminal cross-section 50qmm, busbar compatible with Xpole protective switching devices when using the jaw clamp in combination with standard fork busbar

PropertyValue
Number of poles:2
Rated current:100 A
Rated voltage:415 V
Width in pitch units:2
Switching function:other
With signal lamp:no
Type of voltage:AC
Color of the cap:other
Light source:other
Protection class (IP):IP40
Min. rated voltage:240 V
Short circuit strength (Icw):2 kA
Lamp base:other
Installation depth:69.5 mm

Characteristics

Color of the capOther
Min. rated voltage240 V
HABIS-100/2
ManufacturerEaton
HAN276283
GTIN4015082762834
Rated voltage415V
Rated current100A
Width in pitch units2
Installation depth69.5 mm
Short circuit strength (Icw)2kA
LampsOther
With signal lampNo
Number of poles2
Switching functionOther
IP protection)IP40
Voltage typeAC
