Eaton P1-25/ST/SVB main switch surface mounting, steel housing, 025523

Eaton P1-25/ST/SVB main switch surface mounting, steel housing, 025523

In stock

SKU: 224419

Price on request

€156.56

€0

Overview

Main switch/load-break switch on-off according to IEC/EN 60947-3, 690V/25A in a sheet steel housing, protection class front IP65, red handle with yellow locking ring, lockable with 3 padlocks, the P1 load-break switches are very compact and robustly built. The manual drive acts directly on the contacts. The contacts are automatically opened when switched off. General designs: Insulated surface-mounted housing, installation, central installation, intermediate installation, IVS distribution installation

Property	Value
Number of poles:	3
Rated operating power at AC-23, 400 V:	13 kW
Rated continuous current Iu:	25 A
Max. Rated operating voltage Ue at AC:	690 V
Version as EMERGENCY STOP device:	yes
Protection class (IP), front:	IP65
Connection type main circuit:	screw connection
Device design:	Built-in device, fixed installation technology
Design of the actuating element:	other
Suitable for floor mounting:	no
Integrated motor drive:	no
Suitable for front mounting 4-hole:	no
Version as Maintenance/repair switch:	yes
Voltage release optional:	no
Suitable for front mounting central:	no
Suitable for intermediate installation:	no
Suitable for distribution board installation:	no
Version as main switch:	yes
Version as safety switch:	no
Motor drive optional:	no
Lockable:	yes
Version as reversing switch:	no
