Rated operating current Ie at DC-13, 125 V0.55 A
Rated operating current Ie at AC-15, 24 V6 A
Electronic outputNo
Rated operating current Ie at AC-15, 125 V6 A
HAB3SE5112-0LA00-1CA0 + corrosion protection
HAN3SE5112-0LA00-1CA0
GTIN4011209692480
Number of contacts as normally open1
Number of contacts as opener2
Number of safety-related auxiliary contacts2
Rated operating current Ie at DC-13, 24 V3 A
Width of the sensor40 mm
Suitable for security functionsYes
Height of the sensor37.3 mm
Length of the sensor85.7 mm
With status displayNo
Switching function latchingNo
Protection class (NEMA)12
Ambient temperature during operation-25 to 85 °C
Forced openingYes
