ABB Stotz-Kontakt 2CSR255188R1325 DS201AT-B32A/0.03 6kA 1P+N FI/LS switch

Residual current circuit breakers (RCBOs) provide protection for people and property, as well as protection against electrically ignited fires in accordance with DIN0100-410 and DIN0100-530. They ensure protection of single-phase circuits against overload and short-circuit currents, protection against sinusoidal alternating currents and pulsating currents with a smooth DC residual current component of up to 6 mA to earth. As well as fault protection (protection against indirect contact), additional protection (with I n 30 mA) and fire protection (with I n 300 mA). They meet the product standards IEC/EN 61009-1, IEC/EN 61009-2-1., The provisions according to DIN EN 45545 (fire and smoke protection standard) R22-R26 and Category 1 - Class A and Class B according to IEC 61373 (shock and vibration resistance) make the DS201 AT fit for use in rail vehicles., The extensive range of accessories offers you everything you need for your installation tasks., The approvals are: CCC (China), EAC (Russia), RCM (Australia)., Rated switching capacity according to IEC/EN 61009 Icn = 6 kA., RCBO DS201 AT (Traction) Type A is 1-pole protected (LS), 2-pole switching.
