Eaton PFIM-25/4/03-S/F 25A 4-pole 300mA residual current device, 187362

In stock

SKU: 479676

Price on request

€143.13

€0

Overview

Residual current circuit breaker PFIM-F, 4-pole, rated current In: 25 A, rated short-circuit strength Icn: 10 with backup fuse kA, rated residual current IN: 0.3 A, switching devices for residential and commercial buildings

Property	Value
Rated voltage:	230 V
Rated current:	25 A
Rated residual current:	0.3 mA
Mounting type:	DIN rail
Protection class (IP):	IP20
Frequency:	50 Hz
Number of poles:	4
Width in pitch units:	4
Selective type:	yes
Residual current type:	other
Additional equipment possible:	yes
Installation depth:	70.5 mm
Short-circuit strength (Icw):	10 kA
Surge current strength:	5 kA
Short-time delayed type:	no
Rated insulation voltage Ui:	440 V
Rated impulse withstand voltage Uimp:	4 kV
With locking device:	yes
Ambient temperature during Operating:	-25 to 55 °C
Pollution level:	2
Connectable conductor cross-section, stranded:	1.5 to 16 mm²
Connectable conductor cross-section, single-wire:	1.5 to 35 mm²
