Eaton PXF-100/4/03-KV/A residual current device, 100A, 4p, 300mA, type A, 290224

Eaton PXF-100/4/03-KV/A residual current device, 100A, 4p, 300mA, type A, 290224

In stock

SKU: 218358

Price on request

€1,036.86

€0

Into a basketIn the basketGo

Overview

Residual current circuit breaker, 100A, 4p, 300mA, type A

Eaton Type: PXF-100/4/03-KV/A
Eaton Article No.: 290224

Property	Value
Rated voltage:	400 V
Current:	100 A
Fault current:	0.3 A
Mounting type:	DIN rail
Protection class (IP):	IP20
Frequency:	50 Hz
Number of poles:	4
TE:	4
Selective type:	no
Residual current type:	A
Additional equipment possible:	yes
Installation depth:	70.5 mm
Short-circuit strength (Icw):	10 kA
Surge current strength:	3 kA
Short-time delayed type:	yes
Rated insulation voltage Ui:	440 V
Rated impulse withstand voltage Uimp:	4 kV
With locking device:	yes
Ambient temperature during operation:	-25 to 60 °C
Pollution degree:	2
Connectable conductor cross-section, stranded:	1.5 to 16 mm²
Connectable conductor cross-section, solid:	1.5 to 35 mm²
Type of voltage:	AC
Explosion-proof:	no

Characteristics

HABPXF-100/4/03-KV/A

Manufacturer

HAN290224

GTIN4015082902247

Connectable conductor cross-section solid1.5 to 35 mm²

Connectable conductor cross-section stranded1.5 to 16 mm²

Rated insulation voltage Ui440V

Rated voltage400V

Rated impulse withstand voltage Uimp4kV

Installation depth70.5 mm

Explosion-proofNo

Residual current typeA

Frequency50Hz

Short circuit strength (Icw)10kA

Short-time delayed typeYes

With locking deviceYes

Mounting typeDIN rail

Number of poles4

IP protection)IP20

Selective typeNo

Voltage typeAC

Surge current strength3kA

TE4

Ambient temperature during operation-25 to 60 °C

Degree of contamination2

Additional equipment possibleYes
