Eaton PXF-40/4/05-A residual current device, 40A, 4p, 500mA, type A, 236779

In stock

SKU: 218379

Price on request

€50.35

€0

Overview

Residual current circuit breaker PXF, 4-pole, rated current In: 40 A, rated short-circuit strength Icn: 10 kA, rated residual current IN: 0.5 A, switching devices for residential and commercial buildings

Property	Value
Rated voltage:	400 V
Rated current:	40 A
Rated residual current:	0.5 mA
Mounting type:	DIN rail
Protection class (IP):	IP20
Frequency:	50 Hz
Number of poles:	4
Width in pitch units:	4
Selective type:	no
Residual current type:	A
Additional devices possible:	yes
Installation depth:	70.5 mm
Short-circuit strength (Icw):	10 kA
Surge current strength:	0.25 kA
Short-time delayed type:	no
Rated insulation voltage Ui:	440 V
Rated impulse withstand voltage Uimp:	4 kV
With locking device:	yes
Ambient temperature during Operating:	-25 to 60 °C
Pollution level:	2
Connectable conductor cross-section, stranded:	1.5 to 16 mm²
Connectable conductor cross-section, single-wire:	1.5 to 35 mm²
