Eaton PXF-63/4/03-KV/A residual current device, 63A, 4p, 300mA, type A, 290223

Eaton PXF-63/4/03-KV/A residual current device, 63A, 4p, 300mA, type A, 290223

In stock

SKU: 218387

Price on request

€257.72

€0

Into a basketIn the basketGo

Overview

Residual current circuit breaker PXF, 4-pole, rated current In: 63 A, rated short-circuit strength Icn: 10 kA, rated residual current IN: 0.3 A, switching devices for residential and commercial buildings

Property	Value
Rated voltage:	400 V
Rated current:	63 A
Rated residual current:	0.3 mA
Mounting type:	DIN rail
Protection class (IP):	IP20
Frequency:	50 Hz
Number of poles:	4
Width in pitch units:	4
Selective type:	no
Residual current type:	A
Additional devices possible:	yes
Installation depth:	70.5 mm
Short-circuit strength (Icw):	10 kA
Surge current strength:	3 kA
Short-time delayed type:	yes
Rated insulation voltage Ui:	440 V
Rated impulse withstand voltage Uimp:	4 kV
With locking device:	yes
Ambient temperature during Operating:	-25 to 60 °C
Pollution level:	2
Connectable conductor cross-section, stranded:	1.5 to 16 mm²
Connectable conductor cross-section, single-wire:	1.5 to 35 mm²

Characteristics

HABPXF-63/4/03-KV/A

Manufacturer

HAN290223

GTIN4015082902230

Connectable conductor cross-section solid1.5 to 35 mm²

Connectable conductor cross-section stranded1.5 to 16 mm²

Rated residual current0.3mA

Rated insulation voltage Ui440V

Rated voltage400V

Rated impulse withstand voltage Uimp4kV

Rated current63 A

Width in pitch units4

Installation depth70.5 mm

Residual current typeA

Frequency50Hz

Short circuit strength (Icw)10kA

Short-time delayed typeYes

With locking deviceYes

Mounting typeDIN rail

Number of poles4

IP protection)IP20

Selective typeNo

Surge current strength3kA

Ambient temperature during operation-25 to 60 °C

Degree of contamination2

Additional equipment possibleYes
