HABT5B-4-8410/I4
HAN207234
GTIN4015082072346
Connection type main circuitScrew connection
Design of the actuating elementShort twist grip
Rated operational power at AC-3, 400 V37kW
Rated operational current Ie at AC-3, 400 V41 A
Rated continuous current Iu63 A
Suitable for floor mountingYes
Suitable for front mountingNo
Suitable for distribution board installationNo
Suitable for intermediate constructionNo
Complete device in housingYes
With zero settingYes
With retraction to zero positionNo
NEMA protection class, front12
Number of poles3
Protection class (IP), frontIP65
Housing materialPlastic
