Rocker switch 42 V nominal current 1 A with push-button switch, with screw terminal connection, built-in rocker switch illuminated, colour: pearl white for flush mounting, cover 80x80mm, for built-in box item no. 506400, operating voltage 12 V - 24 V, LED current consumption: at 12 V approx. 2 mA not for remote control dimmers and electronic remote control relays except item no. 517770
| Property | Value |
| Color: | cream white (electric white) |
| Design: | Single button |
| Suitable for protection class (IP): | IP20 |
| Contacts: | 1 normally open contact |
| Operating method: | Push button |
| Mounting type: | Flush-mounted |
| Number of Rocker switches: | 1 |
| Halogen-free: | yes |
| Text field/labeling area: | no |
| Composition: | Base element with complete housing |
| Feedback contact: | no |
| With lighting: | yes |
| Mounting type: | Screw fastening |
| Material: | Plastic |
| Material quality: | Thermoplastic |
| Surface: | untreated |
| Surface finish: | glossy |
| RAL number (similar) : | 1013 |
| Nominal voltage: | 42 V |
| Number of modules (with modular construction) : | 2 |
| Print: | without |
| Rated current: | 1 A |
| Device width: | 80 mm |
| Device height: | 80 mm |
| Device depth: | 41 mm |
| Number of poles: | 1 |
| Transparent: | no |
| Antibacterial treatment: | yes |
| With signal lamp: | no |
