ELSO ELG174411 Potentiometer with push button switch 200mA

In stock

SKU: 433225

Price on request

€36.95

€0

Overview

with push-button switch for controlling dimmable electronic ballasts (EVG) with push-button switch 230 V, 50 Hz, 6 A (note the inrush current of the EVGs), with minimum setting, memory function Control voltage: 1-10 VDC Control current: max. 200 mA Fuse: 6.3 A Type: SBD1-10

Property	Value
Dimming leading edge:	no
Dimming trailing edge:	no
Mounting type:	flush-mounted
Color:	gray
Suitable for protection class (IP):	IP20
Operating method:	Rotary/push button
Halogen-free:	yes
Composition:	Basic element
Load type:	EVG 1-10 V
Series dimmer:	no
Extension input:	no
Light value memory:	yes
Can be used with button:	no
Can be used with motion detector:	no
Can be used with presence detector:	no
Can be used with timer:	no
Can be used with radio button:	no
Can be used with IR button:	no
Mounting type:	Mounting with screw
Material:	other
Material quality:	other
Surface:	untreated
Frequency:	50 Hz
Device width:	71 mm
Device height:	71 mm
Device depth:	29 mm
Rated power:	400 VA
Nominal voltage:	230 V
Control voltage:	10 V
Transparent:	no
App control via Bluetooth:	no
Connection type:	screw terminal
Wire cross section:	1.5 mm
Min. depth of device box:	46 mm
