HANHIC420E
GTIN3250613131760
Connection type main circuitCable clamp
Number of auxiliary contacts as normally open1
Number of switches1
Designed as main switchYes
Designed as an EMERGENCY STOP deviceNo
Designed as a safety switchYes
Designed as a maintenance/repair switchYes
Version as reversing switchYes
Design of the actuating elementOther
Conditional rated short-circuit current Iq50kA
Rated operational power at AC-23, 400 V90kW
Rated operating voltage380 to 415 V
Rated continuous current Iu200A
Rated continuous current at AC-21, 400 V200A
Rated continuous current at AC-23, 400 V200A
Rated short-time withstand current Icw12kA
Color of the actuatorOther
Suitable for floor mountingYes
Suitable for front mounting 4-holeNo
Suitable for front mounting CentralNo
Suitable for distribution board installationYes
Suitable for intermediate constructionNo
Device typeBuilt-in device Fixed installation technology
Max. rated operating voltage Ue at AC415V
Motor drive integratedYes
Motor drive optionalNo
Number of poles4
Switching capacity at 400 V131kW
Protection class (IP), frontIP00
Protection class (NEMA)Other
Voltage release optionalNo
LockableYes
