ABB Stotz-Kontakt TS16/4-8-12 , bell transformer 16VA, 4-8-12VAC , 2CSM228625R0812

In stock
SKU: 321272
€35.71
Into a basketIn the basketGo

Overview

TS series transformers for supplying extra-low voltage (SELV), suitable for loads that require short-term supply, particularly doorbells and chimes. In addition to perfect insulation and separation between the primary and secondary circuits, TS transformers have a thermal protection device integrated in the secondary part, making them resistant to short-circuit currents (conditionally short-circuit-proof). They are equipped with a thermal protection device that automatically restores operation when the transformer has cooled down sufficiently or the overload has been eliminated. The ...ES series bell transformers are characterized by 50% reduced energy consumption in idle mode.

PropertyValue
Type of transformer:Standard bell transformer
Primary voltage:230 V
Width in pitch units:2
Secondary voltage 1:4 V
Secondary voltage 2:8 V
Secondary voltage 3:12 V
Secondary current 1:4 A
Secondary current 2:2 A
Secondary current 3:1.33 A
Suitable for flush-mounted installation:no
Short-circuit proof:yes
Suitable for surface-mounted installation:no
Length:65 mm
Width:35 mm
Height:85 mm
Max. output power:16 W
Suitable for series installation:yes
Temperature protection:yes
Max. Output current:4 A
Max. power dissipation:4 W
With on/off switch:no

Characteristics

Secondary voltage 14 V
HABTS16/4-8-12
ManufacturerABB Stotz-Kontakt
HAN2CSM228625R0812
GTIN8012542286257
Width35 mm
Width in pitch units2
Suitable for series installationYes
Height85 mm
Length65 mm
With on/off switchNo
