Performance characteristics Digital/Universal Twin LNC, Number of LNC outputs: 2, Min. reception frequency range: 10.7 GHz, Max. reception frequency range: 12.75 GHz, Output frequency lower limit: 950 MHz, Output frequency upper limit: 2150 MHz, Noise figure: 0.8 dB, Aperture angle/half width: 3 °, 1st oscillator frequency: 9.75 GHz, 2nd oscillator frequency: 10.6 GHz, System quality G/T: 13.3 dB/K, System quality determined at 11.3 GHz, Gain: 50 dB, Min. LNC remote power supply: 11.5 V, Max. LNC remote power supply: 19 V, Current consumption: 250 mA, Reflector, Flat antenna, Mechanics/Mounting, Mast mounting, Wall mounting, min. mast attachment: 4.2 cm, max. mast attachment: 5 cm, min. elevation angle: 0 °, max. elevation angle: 90 °, 240 N wind power
Property | Value |
Protection class (IP): | IP68 |
Mirror material: | Plastic |
Mounting material: | Steel |
Design: | flat |
With mast bracket: | yes |
With system bracket: | yes |
Multifeed compatible: | yes |
Support arm completely pre-assembled: | yes |
Color: | white |
Feed holder: | other |
Diameter/edge length: | 50 cm |
Type of feed system/LNB: | Twin universal |
