Reception of two orbital positions with a fixed 45 cm digital satellite antenna. Article information: Material: aluminum Material thickness: 1.6 mm Coating: powder-coated on both sides Technical data: Nominal size: 0.85 m F/D: 0.67 G/T: 17.2 db/K Gain: 38.2 dB , at 11.3 GHz Offset angle: 21 ° Feed holder: Multifeed Power supply: Vertical power supply: 11 ... 14 V Horizontal power supply: 16 ... 20 V LNB power supply: 11 ... 20 V Power consumption: 170 mA (typ.) Noise figure: Lower frequency range: 0.7 dB max. Upper frequency range: 0.8 dB max. Output frequency range: Lower frequency range: 950 1950 MHz Upper frequency range: 1100 2150 MHz Input frequency range: Lower frequency range: 10.7 11.7 GHz Upper frequency range: 11.7 12.75 GHz LOF: Lower frequency range: 9.75 GHz 3MHz Upper frequency range: 10.6 GHz 3MHz Scope of delivery: DigitalSat antenna SATMAN 45, Multytenne DuoSat reception unit (LNB), AZ/EL bracket, wall bracket, screws, tools, assembly instructions
