Design features LNC for two-/multi-user systems: yes SCR single-cable control: yes DiSEqC function for LNC control: yes Min. ambient temperature (-°C): 30 Max. ambient temperature (+°C): 60Performance characteristics Min. input frequency (GHz): 10.7 Max. input frequency (GHz): 12.75 Noise figure (typ.) (dB): 1 1st oscillator frequency (GHz): 9.75 2nd oscillator frequency (GHz): 10.6 Min. remote feed voltage 1 vertical (V): 11.5 Max. remote feed voltage 1, vertical (V): 14 Min. remote feed voltage 2, horizontal (V): 16 Max. remote feed voltage 2, horizontal. (V) : 19 min. output frequency, low band (MHz) : 950 max. output frequency, low band (MHz) : 1950 min. output frequency, high band (MHz) : 1100 max. output frequency, high band (MHz) : 2150 Current consumption (A) : 0.28Connections Number of outputs: 2 Number of SCR outputs: 1Housing properties Weatherproof housing: yes Mounting dimensions, diameter (mm) : 40 Width (cm) : 5.9 Height (cm) : 12.3 Depth (cm) : 14.3 Weight (g) : 0.3
