Design features Switching matrix: active switching matrix Number of inputs: 9 Number of subscriber outputs: 32 Cascadable switch: yes Return channel capable: yes Suitable for digital/universal quad LNC: yesPerformance characteristics Lower limit of frequency response, SAT (MHz): 950 Upper limit of frequency response, SAT (MHz): 2400 Gain, SAT (dB): 10 Max. operating input level, SAT (dBV): 102 Max. operating input level, terr. (dBV): 104 Decoupling of the outputs (dB): 25 Through loss, SAT (dB): 12 Through loss, terr. (dB) : 8 LNC switching voltage 12 V: yes min. ambient temperature (-°C) : 5 max. ambient temperature (+°C) : 45Power consumption/voltage supply Current consumption per participant (mA) : 33Housing properties Width (cm) : 20.8 Height (cm) : 51.9 Depth (cm) : 3 Weight (kg) : 3.1
