Televes OSK2A-500 opt.cable 2 fibers,outdoor 500m

In stock

SKU: 1107

Price on request

€2.04

€0

Overview

2-fiber optical cable (single mode) with LSFH jacket for outdoor installation. Each fiber has its own LSFH jacket and is marked with a specific color. This ensures better clarity and makes identification easier.

Property	Value
Outer diameter approx.:	3 mm
Sheath color:	gray
Fiber type:	Singlemode 9/125
Core type:	Full-loader
Number of fibers per core:	1
With strain relief:	yes
With Rodent protection:	no
Reinforcement:	yes
Sheath material:	Polyvinyl chloride (PVC)
Metal-free cable:	no
Flame-retardant:	no
Low smoke according to EN 61034-2:	yes
Chemically resistant:	yes
Blow-in:	no
Number of fibers:	2
Halogen-free according to EN 60754-1/2:	yes
Oil-resistant according to EN 60811-404:	no
Category:	OS2
Specification of sheath material:	Rubber - ethylene-vinyl acetate copolymer (EVA)
Cable longitudinally watertight:	yes
Cable transversely watertight:	yes
Fire behaviour class according to EN 13501-6:	Dca
Smoke development class according to EN 13501-6:	s2
Drip behaviour class according to EN 13501-6:	d2
Acid development class according to EN 13501-6:	a2
UV-resistant:	yes
Laying in the ground:	no
