Rated service life L90/B10 at 25 °C25000 h
HANEL10750717
GTIN4015120750717
Covering the luminaire with thermal insulation material possibleNo
Connection typeScrew terminal
Type of wiringSuitable for through wiring
Execution of the gridWithout
Rated lifetime L70/B50 at 25 °C100000 hours
Rated lifetime L80/B10 at 25 °C50000 hours
Rated luminous flux according to IEC 62722-2-1850lm
Rated ambient temperature according to IEC62722-2-1-25 to 50 °C
Operating deviceLED control gear current controlled
Suitable for computer workstations according to EN 12464-1No
Width104 mm
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming GPRSNo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming depends on the control gearNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Color temperature3000K
Color rendering index CRI80-89
VersionOther
Suitable for surface mountingYes
Suitable for ceiling mountingNo
Suitable for flush mountingNo
Suitable for number of lamps1
Suitable for light strip configurationNo
Suitable for emergency lightingNo
Suitable for pendulum suspensionNo
Suitable for wall mountingYes
Housing colorBlack
Glow wire test according to IEC 60695-2-11650 °C - 30 s
Height/Depth143 mm
Conductor cross-section2.50 mm²
Luminaire with limited surface temperature D-markNo
Luminaire luminous efficacy85lm/W
LampsLED replaceable
Light emissionDirect
Light colorWhite
Light distributorDiffuser lens/optics/panel
Light distributionSymmetrical
Length205 mm
Max. system performance10.0W
With operating deviceYes
With motion detectorYes
With light sourceYes
With light sensorYes
With air slotsNo
Nominal voltage230V
Without dimming functionYes
Number of poles4
IP protection)IP55
Protection classII
Voltage typeAC
Cover materialGlass opal
Housing materialAluminum
