ABB Stotz-Kontakt 2125BU6W, CEE panel-mounted device plug, 125 A 6h, IP67, standard flange, 2CMA167195R1000

In stock
SKU: 203100
€286.82
Into a basketIn the basketGo

Overview

Industrial connectors are the solution for industrial sectors with high demands on safety, durability, reliability and cost savings for the end user. The range consists of IP44 and IP67 devices from 16 A to 125 A, from simple plugs to flexible customer-specific combination solutions. The products follow an ergonomic and robust design, are quick to assemble and have a long service life. The range covers all current clock positions. The connectors are approved according to IEC 60 309-1, 2- and -4. Country-specific approvals are also available on request.

PropertyValue
IEC current:125
UL/CSA current (if UL version required):125
Voltage according to EN 60309-2:200-250 V (50+60 Hz) blue
Rated voltage:200 to 250
Rated frequency:50 to 60
Number of poles:3
Clock position:6
Identification color:blue
RAL number:7001
Protection class (IP):IP67
Connection technology:screw terminal
Design:surface-mounted device plug
Phase inverter:no
Plug direction:straight
Material:plastic
Military version:no

Characteristics

Rated frequency50 to 60
Phase inverterNo
HAB2125BU6W
ManufacturerABB Stotz-Kontakt
HAN2CMA167195R1000
GTIN7392696671958
Connection technologyScrew terminal
DesignSurface-mounted device plug
Rated voltage200 to 250
IEC current125
Identification colorBlue
Military versionNo
Number of poles3
RAL number7001
Voltage according to EN 60309-2200-250 V (50+60 Hz) blue
Plug directionStraight
Time position6
MaterialPlastic
