Audio:, Number of acoustic call distinctions: 17, Number of parallel calls: 1, Number of selectable ring tones: 24, Automatic Gain Control Audio: No, Automatic call disconnection: yes, Automatic hands-free operation after internal call: can be activated, Busy indicator: No, Floor call possible: Yes, Floor door opener function: can be activated, Import of individual ring tones: possible, Internal call: configurable, Call volume: ring tone and loudspeaker output can be adjusted by the user in 8 levels in the OSD menu, Microphone sensitivity volume: adjustable, Light switching: via OSD menu, Privacy lock: No, Parallel call: configurable, Call acceptance: on talk button, Call display: optical and/or acoustic, Ring tones: adjustable via OSD menu, Ring tone disconnection: in OSD menu, Call forwarding: configurable, Language selection: German / English, Voice transmission: full duplex, Automatic door opener: via OSD menu, Video:, Calling of individual images: possible, Image display/camera selection: OSD menu, image storage per door call: Yes, brightness: OSD menu in 20 levels, brightness setting: OSD menu in 20 levels, contrast setting: OSD menu in 20 levels, color saturation: OSD menu in 20 levels, PTZ control: via OSD menu, user interface:, user apps: email, calendar and internet browser, date display: adjustable, temperature display: can be activated, time display: adjustable, input operation: direct selection buttons and OSD menu, functions in the OSD menu: (de-)activation of the touch function, programming, loading factory settings, text message reception: possible, LED (green): door and internal calls (in absence), automatic door opener or call forwarding activated, TCS text message received, LED (red): ring tone deactivation, menu control: OSD menu, OSD menu: Yes, start screen: individually configurable, sending text messages: via OSD menu, installer interface:, floor button connection: Yes, Ethernet connection: RJ45, operating display: OSD menu, commissioning and configuration: manual, with service device, with configuration software, password protection: Yes, slot: Micro SDHC card, load factory settings: via OSD menu, control:, number of configurable control functions: 20, home automation: central ON / central OFF, IP:, connection type: screw terminals TCS:BUS and LAN connection socket, digital picture frame: Yes, email sending: organizer in the OSD menu, Ethernet: LAN and WLAN, protocols: DHCP, web interface: web browser, camera properties:, recommended mounting height (m): 1.60, display properties:, display resolution: 1280 x 800, display size (cm): 25.6, display size (inches): 10.1, display type: touchscreen, color, electrical properties:, number of wires: 6, information wiring: 6-wire required, 3-wire input current Ipmax (mA): 240, 3-wire idle input current Ia (mA): 0, 32, 3-wire idle input current IP (mA): 78, input voltage (V): 26 +-8%, housing:, housing height (mm): 198, housing width (mm): 280, housing depth (mm): 22, housing material: aluminum, housing surface treatment: anodized, housing color: silver, min. permissible ambient temperature (°C): 0, max. permissible ambient temperature (°C): 40, housing protection class: IP30
| Property | Value |
| Installation technology: | Bus system |
| Color: | Silver |
| Door opener operation: | yes |
| With automatic door opener: | yes |
| Call differentiation: | yes |
| Switching functions: | yes |
| Internal communication: | yes |
| Mounting type: | Surface-mounted |
| Interface design: | WLAN |
| Volume control: | yes |
| Function lamps: | yes |
| Call silencing: | yes |
| Additional device can be connected: | no |
| Tap-proof: | yes |
| With video: | yes |
| Material: | metal |
| Image system: | PAL |
| With memory function: | yes |
| Hands-free: | yes |
| Connection to smartphone possible: | no |
| Hearing aid compatible: | no |
| With touchscreen: | yes |
| Width: | 280 mm |
| Height: | 198 mm |
| Depth: | 22 mm |
