Industrial connectors are the solution for industrial sectors with high demands on safety, durability, reliability and cost savings for the end user. The range consists of IP44 and IP67 devices from 16 A to 125 A, from simple plugs to flexible customer-specific combination solutions. The products follow an ergonomic and robust design, are quick to assemble and have a long service life. The range covers all current clock positions. The connectors are approved according to IEC 60 309-1, 2- and -4. Country-specific approvals are also available on request.
| Property | Value |
| IEC current: | 63 A |
| Number of poles: | 5 |
| Protection class (IP): | IP67 |
| Identification colour: | red |
| Connection technology: | screw terminal |
| Design: | surface-mounted |
| Voltage according to EN 60309-2: | 400 V (50+60 Hz) red |
| Time setting: | 11 h |
| Material: | plastic |
| Mounting type: | External mounting |
| Military version: | no |
| Insulated installation: | yes |
| UL/CSA current rating (if UL version required): | 60 A |
| RAL number: | 7001 |
| Cable entry: | other |
