HAN6023000038
GTIN4024337100857
Number of contacts as normally open1
Number of contacts as opener1
Number of safety-related auxiliary contacts1
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the actuating elementTappet
Design of the electrical connectionPre-assembled with cable
Rated operating current Ie at AC-15, 230 V3 A
Rated operating current Ie at DC-13, 24 V2.8A
Housing coatingPowder coated
Width of the sensor30 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsYes
Housing designCuboid
Weight0,19
Weight unit kg
Height of the sensor16 mm
Length of the sensor74.2 mm
Switching functionSnap action contact
IP protection)IP67
Protection class (NEMA)4X
Ambient temperature during operation-25 - 70 °C
Housing materialMetal
Forced openingYes
