HAN6023000069
GTIN4024337101168
Number of contacts as opener2
Number of safety-related auxiliary contacts2
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the actuating elementRoller tappet
Design of the electrical connectionConnector M12
Alignment of the actuatorRoller tappet straight
Rated operating current Ie at AC-15, 230 V3 A
Rated operating current Ie at DC-13, 24 V2.8A
Housing coatingPowder coated
Width of the sensor30 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsYes
Housing designCuboid
Weight0,12
Weight unit kg
Height of the sensor16 mm
Length of the sensor88 mm
Switching functionSlow-action switching element
IP protection)IP67
Protection class (NEMA)4X
Ambient temperature during operation-25 - 70 °C
Housing materialMetal
Forced openingYes
