HAN6081000104
GTIN4024337095733
Number of contacts as normally open1
Number of contacts as opener1
Number of safety-related auxiliary contacts1
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the actuating elementAdjustable swivel lever
Design of the electrical connectionCable entry (metric)
Rated operating current Ie at AC-15, 230 V3 A
Rated operating current Ie at DC-13, 24 V1.5A
Width of the sensor42.5 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsYes
Housing designCuboid
Weight0,24
Weight unit kg
Height of the sensor72.62 mm
Length of the sensor201 mm
Switching functionSnap action contact
IP protection)IP66/IP67
Protection class (NEMA)4X
Ambient temperature during operation-30 - 75 °C
Housing materialPlastic
