HAN6083000314
GTIN4024337093159
Number of contacts as normally open1
Number of contacts as opener1
Number of safety-related auxiliary contacts1
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the actuating elementWithout
Design of the electrical connectionCable entry (metric)
Rated operating current Ie at AC-15, 230 V3 A
Rated operating current Ie at DC-13, 24 V1.5A
Width of the sensor31 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsYes
Housing designSpecial design
Weight0,06
Weight unit kg
Height of the sensor49.5 mm
Length of the sensor81 mm
Switching functionSnap action contact
Switching function latchingYes
IP protection)IP66/IP67
Protection class (NEMA)4X
Ambient temperature during operation-30 - 75 °C
Housing materialPlastic
Forced openingYes
