HAN6087000068
GTIN4024337099045
Number of contacts as normally open2
Number of contacts as opener2
Number of safety-related auxiliary contacts2
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the actuating elementSwivel lever
Design of the electrical connectionCable entry (metric)
Rated operating current Ie at AC-15, 230 V3 A
Rated operating current Ie at DC-13, 24 V1.5A
Housing coatingPowder coated
Width of the sensor42.5 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsYes
Housing designCuboid
Weight0,26
Weight unit kg
Height of the sensor63.5 mm
Length of the sensor134.7 mm
Switching functionSlow-action switching element
IP protection)IP66/IP67
Protection class (NEMA)4X
Ambient temperature during operation-30 - 75 °C
Housing materialMetal
Forced openingYes
