HAN6087000092
GTIN4024337099267
Number of contacts as normally open2
Number of contacts as opener2
Number of safety-related auxiliary contacts2
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the actuating elementRod lever
Design of the electrical connectionCable entry (metric)
Rated operating current Ie at AC-15, 230 V3 A
Rated operating current Ie at DC-13, 24 V1.5A
Housing coatingPowder coated
Width of the sensor42.5 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsYes
Housing designCuboid
Weight0,28
Weight unit kg
Height of the sensor60.3 mm
Length of the sensor276.7 mm
Switching functionSlow-action switching element
IP protection)IP66/IP67
Protection class (NEMA)4X
Ambient temperature during operation-30 - 75 °C
Housing materialMetal
