HAN6087000108
GTIN4024337099533
Number of contacts as normally open1
Number of contacts as opener1
Number of safety-related auxiliary contacts1
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the actuating elementWithout
Design of the electrical connectionCable entry (metric)
Rated operating current Ie at AC-15, 230 V3 A
Rated operating current Ie at DC-13, 24 V1.5A
Housing coatingPowder coated
Width of the sensor42.5 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsYes
Housing designCuboid
Weight0,18
Weight unit kg
Height of the sensor44.5 mm
Length of the sensor77.5 mm
Switching functionSlow-action contact with overlap
IP protection)IP66/IP67
Protection class (NEMA)4X
Ambient temperature during operation-30 - 75 °C
Housing materialMetal
Forced openingYes
