Rated operating current Ie at DC-13, 230 V0.27 A
Rated operating current Ie at DC-13, 125 V0.22 A
Rated operating current Ie at AC-15, 24 V10 A
HAN6089152048
GTIN4024337072284
Number of contacts as normally open1
Number of contacts as opener1
Number of safety-related auxiliary contacts1
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the actuating elementTappet
Design of the electrical connectionPre-assembled with cable
Rated operating current Ie at AC-15, 230 V3 A
Rated operating current Ie at DC-13, 24 V2.8A
Width of the sensor30 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsYes
Housing designCuboid
Weight0,12
Weight unit kg
Height of the sensor16 mm
Length of the sensor60 mm
Switching functionSnap action contact
IP protection)IP67
Protection class (NEMA)4X
Statistical commodity code85365011
Ambient temperature during operation-25 - 70 °C
Housing materialPlastic
Forced openingYes
