HAN6121190918
GTIN4024337044762
Number of contacts as normally open1
Number of contacts as opener1
Number of safety-related auxiliary contacts1
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the actuating elementSpring bar
Design of the electrical connectionCable entry (metric)
Rated operating current Ie at AC-15, 230 V3 A
Housing coatingPowder coated
Width of the sensor36 mm
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Suitable for security functionsYes
Housing designCuboid
Weight0,18
Weight unit kg
Height of the sensor32.5 mm
Length of the sensor399 mm
Switching functionSnap action contact
IP protection)IP65
Statistical commodity code85365011
Ambient temperature during operation-30 - 80 °C
Housing materialMetal
