Diameter of the sensor8 mm
Mechanical installation condition for sensorFlush
Design of the switching functionOpener
Switching frequency1000 Hz
HAN6532101001
GTIN4024337097706
Type of operationMetallic target
Implementation of the interfaceWithout
Design of the interface for safety-related communicationWithout
Design of the switching outputNPN
Design of the electrical connectionCable
Rated control supply voltage Us at DC10 - 30V
Housing coatingOther
Explosion protection category for gasWithout
Explosion protection category for dustWithout
Housing designCylinder, thread
Weight0,06
Weight unit kg
Length of the sensor34.3 mm
Performance Level according to EN ISO 13849-1Without
SIL according to IEC 61508Without
Switching distance1 mm
Protection class (NEMA)1
Voltage typeDC
Housing materialMetal
