Digital annual timer for distribution board installation
1 channel
Compact housing width 36 mm narrow
Switching capacity 16 A
Permanent switching according to date / holiday program
Daily, weekly and annual program
300 memory locations
'Cycle' function
'DCF' function
'Pulse' function
Illuminated display
'Data key' function
'Timer' function
'Channel button' function
Shortest switching interval 1 minute
Manual permanent switching
Manual switching anticipation
Automatic switching time orientation when reading out
Free block programming
Automatic summer time changeover
Operating hours and Pulse counter
Security through PIN coding
| Property | Value |
| Width in pitch units: | 4 |
| Number of channels: | 1 |
| Protection class (IP): | IP20 |
| Supply voltage: | 230 V |
| Power reserve in years: | 6 |
| Weekly program: | yes |
| Annual program: | yes |
| Mounting type: | DIN rail |
| Type of supply voltage: | AC |
| Frequency of Supply voltage: | 50 to 60 Hz |
| Accuracy per day: | 1 s |
| Text guidance in the display: | yes |
| 24 h program: | yes |
| 60 min program: | no |
| Automatic summer/winter time change: | yes |
| Shortest switching time channel 1: | 1 min |
| Holiday program: | yes |
| Pulse program: | yes |
| Cycle program: | yes |
| Astro program: | no |
| External button input: | yes |
| Random program: | no |
| Operating hours counter: | yes |
| Quartz-controlled: | yes |
| Radio-controlled: | yes |
| Shortest switching time channel 2: | 1 min |
| Manual operation: | yes |
| Number of memory locations: | 300 |
| Switching preselection: | yes |
| Nominal switching current at 250 V AC: | 10 A |
| Potential-free switching contact: | yes |
| Width: | 72.0 mm |
| Height: | 58.0 mm |
| Depth: | 45.0 mm |
| External programming: | yes |
| Radio controlled (DCF77): | yes |
| GPS: | no |
