Connectable conductor cross-section1.5 to 2.5 mm²
HABFL3N-LED white
HAN92703
GTIN4007529927036
Covering the luminaire with thermal insulation material possibleNo
Connection typeScrew terminal
Type of wiringSuitable for through wiring
Beam angleWide beam 41-80°
Rated ambient temperature according to IEC 62722-2-1-20.0 to 40.0 °C
Operating deviceNot required
Suitable for computer workstations according to EN 12464-1No
Width125.0 mm
Dimming 0-10 VNo
Dimming 1-10 VNo
Dimming DALINo
Dimming DMXNo
Dimming DSINo
Dimming LineSwitchNo
Dimming mains voltage modulationNo
Dimming trailing edgeNo
Dimming phase controlNo
Dimming potentiometer (integrated)No
Dimming RFNo
Dimming Sine Wave ReductionNo
Dimming Touch and DimNo
Dimming ZigbeeNo
Dimming manufacturer-specificNo
Dimming with push buttonNo
Dimming programmableNo
Color temperature4000.0K
Color rendering index CRI80-89
VersionWithout
Suitable for surface mountingYes
Suitable for ceiling mountingNo
Suitable for flush mountingNo
Suitable for clamp mountingNo
Suitable for lamp power14W
Suitable for pendulum suspensionNo
Suitable for podium/floor mountingNo
Suitable for rope systemNo
Suitable for busbar mountingNo
Suitable for truss mountingNo
Housing colorWhite
Height/Depth218 mm
Power factor0.7
Conductor cross-section1.5 mm²
Luminaire luminous efficacy75.0lm/W
LampsLED not replaceable
Light colorWhite
Luminous flux1050.0lm
Light intensity539.0 cd
Light distributorReflector
Light distributionSymmetrical
Length136 mm
With operating deviceYes
With motion detectorNo
With light sourceYes
With light sensorNo
Nominal voltage110 to 240 V
Brushed surfaceNo
Surface protectionOther
Without dimming functionYes
Photobiological safety according to EN 62471RG0
ReflectorFrosted
Impact resistanceIK05
IP protection)IP44
Protection classI
Voltage typeAC
System performance14W
AdjustabilitySwiveling
Cover materialGlass transparent
Housing materialAluminum
