Bticino 332240 call button module with 4 call buttons analogue

In stock

SKU: 248988

Price on request

€29.14

€0

Overview

Call button module for analogue video and door intercom systems for installation in the module carrier with 4 call buttons with soffit lighting for nameplates. Connection with plug-in terminals. The other function modules are connected using the included connection cables. Dimensions: 100 x 89 x 45 mm

Property	Value
Height:	89.4 mm
Width:	102.5 mm
Material:	plastic
RAL number (similar):	9016
Mounting direction:	vertical
Number of units:	1
Color:	other
Protection class (IP):	IP20
Suitable for built-in installation:	no
Halogen-free:	yes
With hinged lid:	no
Text field/labeling area:	no
Depth:	15.9 mm
Suitable for underfloor duct box:	no
Suitable for device installation duct:	no
Material quality:	Thermoplastic
Surface:	other
Surface finish:	matt
Number of units horizontal:	1
Number of units vertically:	1
Number of modules horizontally (with modular construction):	1
Number of modules vertically (with modular construction):	1
Mounting type:	other
Transparent:	no
Number of switch inserts:	1
With mounting frame:	no
Impact resistance:	IK07
