Busch-Jaeger 3095-1 box

In stock

SKU: 118363

Price on request

€7.11

€0

Overview

Box, die-cast aluminum/special devices, Busch-Perilex according to DIN 49445-48, 3 P + N + E, 16/25 A, 415 V, box for flush-mounted socket 2365 SR W. Protection class device: IP 20

Property	Value
With screws:	no
Depth:	115 mm
Length:	96 mm
Width:	115 mm
Material:	plastic
Color:	black
Sealable:	no
Halogen-free:	yes
Protection class (IP):	IP20
Shape:	round
Diameter:	96 mm
Mounting type:	other
Design:	Perilex
Design:	Device box
With nail tabs:	no
Windproof:	no
Insertion from the rear:	no
Can be coupled:	yes
Housing feed-through through sealing membrane:	no
Cover fastening:	snap-on
Functional integrity:	without
For number of device inserts:	1
Inner depth:	54 mm
Surface:	untreated
Fastening of devices:	screws
For pipe diameter:	16/19 mm
Pipe locking:	no
Clamp fixed in position:	no
Equipment:	without
Light hook fastening:	no
Socket:	without
With shielding:	no
Housing feed-through through knockout opening:	no
With rotating ring:	no
Special application:	without
Housing feed-through through pipe socket:	no
Housing feed-through through stepped membrane:	no
Pipe locking optional:	no
Cover design:	without
Transparent cover:	no
