Busch-Jaeger 2722 U blind switch insert, 2-pole

In stock
SKU: 121983
€25.66
Into a basketIn the basketGo

Overview

Blind switch insert, flush-mounted mounting boxes and inserts, inserts for blind control/timers, blind switch insert 2-pole with rotary handle/button. Nominal current: 10 A Protection class device: IP 20 IEC60669-1, British Standard EN 60669-1

PropertyValue
Color:white
Version:2-pin pushbutton
Suitable for protection class (IP):IP20
Operating method:Rotary knob
Nominal voltage:250 V
Halogen-free:yes
Mounting type:Flush-mounted
Text field/labeling area:no
Composition:Basic element
Electrical and mechanical Locking:yes
Mechanically operated:yes
Electronically operated:no
Material:plastic
Material quality:Duroplast
Surface:untreated
Surface finish:matt
Mounting type:claw/screw fastening
RAL number (similar):1013
Rated current:10 A
Transparent:no
Number of poles:2
Min. depth of device box:40 mm

Characteristics

Insert Module TypeBlind covers
HAB2722 U
ManufacturerBUSCH-JAEGER
HAN2CKA001101A0559
GTIN4011395041000
VersionButton 2-pole
Surface finishFrosted
Operating moderotary knob
Mounting typeClaw/screw fastening
Rated current10A
ColorWhite
Suitable for outdoor useNo
Suitable for protection class (IP)IP20
Halogen freeYes
Min. depth of the device box40 mm
Mounting typeFlush-mounted
Nominal voltage250V
SurfaceUntreated
Number of poles2
RAL number (similar)1013
Text field/label areaNo
TransparentNo
MaterialPlastic
Material qualityDuroplast
CompilationBasic element
