Busch-Jaeger 20 EWSL-54 SCHUKO® socket alpine white

Busch-Jaeger 20 EWSL-54 SCHUKO® socket alpine white

In stock

SKU: 118916

Price on request

€42.91

€0

Overview

With plug connection. With security lock in the hinged lid. 2 P + E, lockable. 2 keys. Cannot be unscrewed or removed when locked. Approx. 200 different locks (not sorted), can be labeled with label holder 1763-53. Suitable labeling software at www.BUSCH-JAEGER-Beschriftungstool.de.

Property	Value
RAL number (similar):	9010
Number of units:	1
Color:	white
Suitable for protection class (IP):	IP44
Nominal voltage:	250 V
Nominal current:	16 A
Lockable:	yes
With increased contact protection:	no
With hinged lid:	yes
Mounting type:	Surface-mounted
Text field/labeling area:	yes
Frequency:	50 Hz
Ejection mechanism:	no
Halogen-free:	yes
Surge protection:	no
Residual current protection:	no
Special power supply:	without special power supply
Twisted central insert:	no
Connection type:	Plug-in terminal
With Fine-wire fuse:	no
Mounting type:	Mounting with screw
Material:	Plastic
Material quality:	Thermoplastic
Surface:	untreated
Surface finish:	matt
Number of modules (with modular design):	1
Device width:	83 mm
Device height:	55 mm
Device depth:	74 mm
Insulated installation:	yes
With loop-through function:	yes
With on/off switch:	no
With built-in USB power supply:	no
With function lighting:	no
With orientation lighting:	no
Impact resistance:	IK04
Transparent:	no
Protective contact:	yes
Protective conductor contact round:	no
Number of active contacts (round):	2
With Signal lamp:	yes
Number of phases:	1
Antibacterial treatment:	no

Characteristics

ColorWhite

HAB20 EWSL-54

Manufacturer

HAN2CKA002083A0832

GTIN4011395079621

LockableYes

Connection typePlug-in terminal

Antibacterial treatmentNo

Number of Units1

Number of modules (for modular construction)1

Number of phases1

Number of active contacts (approx.)2

Surface finishFrosted

Ejection mechanismNo

Mounting typeFastening with screw

Color

Residual current protectionNo

Frequency50Hz

Suitable for protection class (IP)IP44

Device width83 mm

Device height55 mm

Device depth74 mm

Halogen freeYes

Insulated installationYes

With loop-through functionYes

With on/off switchNo

With micro fuseNo

With functional lightingNo

With hinged lidYes

With orientation lightingNo

With signal lampYes

With built-in USB power supplyNo

With increased contact protectionNo

Mounting typeSurface-mounted

Nominal voltage250V

Rated current16A

SurfaceUntreated

RAL number (similar)9010

Impact resistanceIK04

Protective contactYes

Protective conductor contact roundNo

Special power supplyWithout special power supply

Text field/label areaYes

TransparentNo

Twisted central insertNo

MaterialPlastic

Material qualityThermoplastic

Overvoltage protectionNo
